INSIGHT Thoracic Imaging Film
Capture low- and high-density anatomical structures in one exposure. INSIGHT Thoracic Imaging Film captures and displays a full range of contrast tones for low- and high-density anatomical structures―lung parenchyma to mediastinum―on a single sheet of film. Asymmetric emulsion/screen design provides a balance of exposure contrast levels that increase diagnostic confidence and decrease the amount of examinations, without compromising anatomical visualization.
- Features
- Options
- Support
- Available Sizes
Features
INSIGHT thoracic imaging film is used in INSIGHT thoracic imaging systems to:
- Increase the quality and volume of information available for diagnosis
- Increase confidence for interpreting that information
- Decrease the number of repeat examinations
Zero-crossover film technology and asymmetric film emulsion/screen pairings allow these systems to capture two distinct images with one exposure.
- An image optimized to display lung parenchyma is captured on one side of the film.
- An image optimized to satisfy exposure parameters for mediastinum, retrocardiac, and sub-diaphragmatic anatomy is captured on the other side.
This asymmetric emulsion/screen design provides a full balance of exposure contrast levels (compared to conventional rare-earth film-screen combinations) without compromising anatomical visualization. On the viewbox, the two resultant images are perfectly aligned on one film due to excellent film-screen contact and strict manufacturing specifications.
Options
INSIGHT thoracic imaging system
Standard contrast:
- INSIGHT thoracic imaging film
- INSIGHT thoracic imaging screens
- X-OMAT cassette
- Speed: 250 / mid-lung contrast: 1.40 / mediastinal contrast: 0.7
With the widest latitude, this system provides lower lung-field contrast and higher mediastinal contrast. This standard level of contrast may be preferred by radiologists accustomed to reading chest images with a very long grayscale.
High lung-field contrast:
- INSIGHT thoracic imaging film
- INSIGHT HC thoracic imaging screens
- X-OMAT cassette
- Speed: 335 / mid-lung contrast: 2.00 / mediastinal contrast: 0.5
This system provides higher lung-field and lower mediastinal contrast than the standard-contrast system described above. Overall system contrast is closest to the look of most conventional thoracic imaging systems.
Support
Film storage
Store unopened boxes in a cool, dry place (50–75°F/10–23°C; 30–50% relative humidity) shielded from x-rays and other penetrating radiation.
Safelighting
Use safelight filter type GBX-2 or equivalent located at least 4 ft/1.2 m from the film.
Recommended processing
For best results, process film in X-OMAT and X-OMAT EX II chemicals
Available Sizes
INSIGHT thoracic imaging film
100-sheet box. Sheet sizes—not interleaved.
Size CAT No.
40 x 40 cm 157 2916
35 x 43 cm 828 8201
35 x 35 cm 107 8187
For other sizes or formats, please contact
your Carestream Health, Inc. sales representative.
